The Sailscasts Blog

Migrating your Sails actions to actions2

Actions are Sails mechanisms that are responsible for responding and handling requests to your Sails applications. This article will introduce you to the actions2 style of writing actions in Sails and how to start using it in your Sails applications.

When writing Sails applications, your application's business logic will pretty much be encapsulated in actions - functions that are mapped to routes in your application so when a request is made to a particular route, the action mapped to it is executed. This methodology is not unique to Sails alone by the way as it is common with most web frameworks in different languages.

Classic action form

Prior to Sails v1.0, actions where typically defined as a function that takes in the req incoming request object and res outgoing response object as the first and second arguments respectively and then you return a response from the function which will be sent back to the caller of that action. Below is a typical classic action definition:

module.exports = async function viewDashboard (req, res) {
  const userId = req.param('userId');
  if (!_.isNumeric(userId)) {
    return res.badRequest(new Error('The user id is required!'));
  }
  const user = await User.findOne({ id: userId });
  if (!user) {
    return res.redirect('/register');
  }
  return res.view('dashboard', {username: user.username});
}

The above style of defining actions might be familiar if you've written some Express Route handlers before. However, there are some drawbacks to writing actions this way. Let's look at a few of these drawbacks:

  • There is no declarative way to tell what the action does without dissecting the code.
  • There is no way to specify what request parameters an action expects to receive.
  • Validation logic is mixed with business logic.
  • The action is tightly coupled to the req and res argument making it not reusable.
  • The possible outputs of the action can't be known without traversing the code.

These drawbacks/limitations could be improved on or totally removed by using the actions2 syntax for writing Sails actions.

Introducing actions2

Since Sails v1.0, actions2 is a more modern and declarative syntax for writing actions. This syntax is powered by the node machine specification.

To better understand what machines are, check out this article.

How actions2 work

As mentioned earlier, the actions2 syntax is powered by the node machine specification. When you write your actions in actions2, Sails will use machine-as-action module to build a modified version of a machine that proxies its inputs from request parameters and proxies its exits through the response.

What this means is that the inputs you specify in your action will be populated when the action is called from the request parameters and the exits you return will be sent out as a response from the action. Let's see how the previous action we defined above will look like using the actions2 syntax:

module.exports = {
   friendlyName: 'View Dashboard',
   description: 'Look up the specified user and sends the user to the dashboard, or redirect to a registration page if no user was found.',

  inputs: {
      userId: {
        description: 'The ID of the user to look up.',
        type: 'number',
        required: true
      }
   },
   exits: {
      success: {
        description: 'User was found and sent to the dashboard'
        responseType: 'view',
        viewTemplatePath: 'pages/dashboard'
      },
      notFound: {
        responseType: 'redirect',
        description: 'No user with the specified ID was found in the database.',
      }
   },

   fn: async function (inputs, exits) {
      var user = await User.findOne({ id: inputs.userId });

      if (!user) { throw { notFound: '/register'} }

      return exits.success({username: user.username})
   }
};

Let's look at some advantages of writing actions in this form.

actions2 syntax provides a declarative way to tell what the action does without dissecting the code

At a single glance, the actions2 syntax gives you metadata that tells you what this action is all about thanks to the machine specification. We know what parameters this action expects and the possible response it can give.

Request parameters expected by action is declared explicitly

Using the actions2 syntax, you explicitly declared what parameters the action cares about. This guarantee that you’ll be able to ascertain the names and types of the request parameters the action expects.

Validation logic is pulled out of the action's body

The validation for each request parameter is now defined inside the inputs object. This removes the clutter from the action body leaving it to focus mostly on the business logic of the application. What Sails does is to automatically ensure those validation declarations are held true in each input and respond with a res.badRequest() when any of those constraints is not met by any of the incoming request parameters even before the action runs.

The action is no longer tightly coupled to the req and res objects

With this new syntax, actions are no longer dependent on the req and res object which makes it easier to re-use or abstract into a helper

The possible outputs of the action can be known without traversing the code

With actions2, we have an exits object which holds all the possible exits of an action(See the machine specification for more details). In machine terminology, these are called signals. So without looking at the code, you can see what possible ways an action can exit(return a response).

Using exits in actions2

In an action throwing anything will trigger the error exit by default. If you want to trigger any other exit, you can do so by throwing a "special exit signal". This will either be a string (the name of the exit), or an object with the name of the exit as the key and the output data as the value. For example instead of the usual exit syntax:

 return exits.hasNotSubscribed();

We can use the shorthand:

 throw 'hasNotSubscribed';

Or if you want to pass output data you can use:

throw { hasNotSubscribed: {courseName: 'Developing production-ready Sails Applications'};

Customizing Response

For each exit in an actions2 action, you can optionally specify the following properties:

  • responseType
  • statusCode
  • viewTemplatePath

responseType

The responseType property can be one of the following values:

  • "" (an empty string): This is the standard responseType value and it signals sails to intelligently determine the responseType of the exit based on context: this might send plain text, download a file, transmit data as JSON, or send no response body at all. Note: This is the default responseType and you don't need to specify this value as Sails will infer it if a responseType is not set in an exit.
  • "view": This causes an exit to render and respond with a view; Any output provided to an exit with a responseType of view be provided as view locals.
  • "redirect": This will redirect to a URL provided by the exit output. We used this in our example action above

statusCode

This is the statusCode to respond with. By default, Sails will set the success exit to a status code of 200, you can override this with the statusCode option if you need to. Also, responseType of redirect will have a status code of 304 while every other exit signal will have a 500 status code except specified otherwise.

viewTemplatePath

This is the relative path (from the views/ directory) of the view to render. It is only relevant if responseType is set to "view".

Migrating your codebase to use actions2

So let's say you have a login and signup action in a controller called UserController which looks like this:

// api/controllers/UserController.js
var Passwords = require('machinepack-passwords');
login: function(req, res) {
   if (!req.params('email')) return res.badRequest()
    if (!req.params('password')) return res.badRequest()
   try {
    const foundUser = await User.findOne({email:req.param('email')})
    if (!foundUser) return res.notFound();
    Passwords.checkPassword({
        passwordAttempt: req.param('password'),
        encryptedPassword: foundUser.encryptedPassword
      }).exec({
        error: function(error) {
           return res.serverError(error)
        }
        incorrect: function() {
          return res.notFound();
        },
        success: function() {
          req.session.userId = foundUser.id;
          return res.redirect('/dasboard');
        }
    } catch(error) {
        return res.serverError(error)
    }
  },

and in your routes.js file you map the actions like so:

"PUT /user/login": "UserController.login",

Let's begin migrating these sections to use actions2 but first, let's look at a concept introduce in Sails v1.0

Standalone actions

It's recommended to use standalone actions in your Sails applications for a couple of reasons:

  • It's easier to keep track of the actions that your app contains by looking at the files contained in a folder than by scanning through the code in a controller file.
  • each action file is small and easy to maintain, whereas controller files tend to grow as your app grows
  • blueprint index routes apply to top-level standalone actions, so you can create an api/controllers/index.js file and have it automatically bound to your app’s / route (as opposed to having to create an arbitrary controller file to hold the root action)

So instead of having a controller file that looks like this:

module.exports = {
  login: function (req, res) { ... },
  logout: function (req, res) { ... },
  signup: function (req, res) { ... },
};

With standalone actions, you have the following folder structure:

api/
 controllers/
  user/
   login.js
   logout.js
   signup.js

With that out of the way let's migrate the login classic action to actions2.

Step 1 - Generate the action file

Sails make it easy to write actions2 action by providing a CLI command to scaffold a boilerplate for the action. To do running the following command in your terminal

sails generate user/login

Sails will look for a user directory in the controllers directory and if it finds one it will generate a login.js file with a scaffold for the actions2 syntax or it will create the user directory and then generate the login.js file inside it.

Step 2 - declare the expected inputs

Looking at the login action we will see it's expecting an email and password request parameters. Let's add that to the inputs of user/login.js:

inputs: {
    email: {},
    password: {}
}

Step 3 - Move validation logic into input declaration

We can now move the validation logic in the action body into the individual input declaration. And since we are using actions2 syntax we can do so much more:

inputs: {
    email: {
        description: 'An email address linked to a user in the database',
        example: 'ryan@dahl.com'
        type: 'string',
        isEmail: true,
        required: true
    },
    password: {
        description: 'Password linked to a use record',
        example: 'abc123',
        type: 'string',
        required: true
    }
}

Step 4 - Specifying exit signals

From the classic login action we identify the following lines:

  • return res.notFound()
  • return res.serverError()
  • return res.redirect()

These are all possible exits for the action so let's declare these exits using the actions2 syntax:

exits: {
    success: {
        responseType: 'redirect'
    },
    notFound: {
        description: 'User not found with the email address provided or password do not match email provided'
        statusCode: 404
    }
}

Note we did not define an exit corresponding to res.serverError as this will be inferred by Sails when we throw an error in the action.

Finally, we will write the business logic of the action in the fn function:

{
// ...
fn: async function(inputs, exits) {
    try {
      const foundUser = await User.findOne({email: inputs.email})
       if (!foundUser) throw 'notFound';

    Passwords.checkPassword({
        passwordAttempt: inputs.password,
        encryptedPassword: foundUser.encryptedPassword
      }).exec({
        error: function(error) {
           throw error
        }
        incorrect: function() {
          throw 'notFound'
        },
        success: function() {
          this.req.session.userId = foundUser.id;
          return exit.success('/dasboard');
        }
      })
    } catch(error) {
        throw error
    }
  }
}

And we are done!. Oh one last thing, we have to update the route definition in routes.js to this:

"PUT /user/login" : "user/login";

You can take this approach to migrate your classic actions in your project to use the recommended actions2 style of authoring actions in Sails and start enjoying the benefits stated above. Here are a few more things worthy of note:

  • we still have access to the res and req objects when we need it by using this.req and this.res respectively.
  • We did not need to validate parameters in the action body as that is taking care of in the definitions of the input.
  • You can using object destructuring on the inputs argument so you don't have to use dot notation to access your inputs. like so:
 fn: async function({email, password}, exits) { ... }

Below is the complete login action definition using actions2:

// api/controllers/user/login.js
var Passwords = require('machinepack-passwords');
module.exports = {
    friendlyName: 'Login',
    inputs: {
        email: {
        description: 'An email address linked to a user in the database',
        example: 'ryan@dahl.com'
        type: 'string',
        isEmail: true,
        required: true
    },
    password: {
        description: 'Password linked to a use record',
        example: 'abc123',
        type: 'string',
        required: true
    }
   },
   exits: {
    success: {
        responseType: 'redirect'
    },
    notFound: {
        description: 'User not found with the email address provided or password do not match email provided'
        statusCode: 404
    }
   },
    fn: async function(inputs, exits) {
    try {
      const foundUser = await User.findOne({email:inputs.email})
      if (!foundUser) throw 'notFound';

    Passwords.checkPassword({
        passwordAttempt: inputs.password,
        encryptedPassword: foundUser.encryptedPassword
      }).exec({
        error: function(error) {
           throw error
        },
        incorrect: function() {
          throw 'notFound'
        },
        success: function() {
          this.req.session.userId = foundUser.id;
          return exit.success('/dashboard');
        }
      })
    } catch(error) {
        throw error
    }
  }
}

Conclusion

actions2 is the recommended way of writing actions in Sails and it provides a standardized modern style for writing actions in Sails.js offering you and your team the ability to see at a glance what an action is expecting as request parameters, the possible way an action can exit and other metadata that makes the action self-documenting. Here are further resources:
